Designation: The 6x19S+FC construction describes a wire rope with 6 strands of 19 wires each in a compact design (“S” = seal construction) and a fiber core (FC = Fibre Core).

Properties: If you need a particularly flexible and elastic rope, we can recommend the 6x19S+FC construction. In this special strand construction, thicker outer wires are arranged on a layer of thinner inner wires, which ensures a smooth surface, good load distribution and increased abrasion resistance.

Application: Ideal for applications with high bending loads where reliability and durability are required. The design is also suitable for cable guides with narrow deflections, cable hoists, lifting technology or mechanically moving systems in industry.

Material: Available in stainless steel for use in damp or aggressive environments, e.g. in agriculture. Alternatively, we can also offer the wire rope in galvanized.

Versions at Hamburger Drahtseilerei: We supply the rope, for example, in the 6x19S+FC version as a high-quality manure removal rope made of stainless steel, on request also with coating (in the 6×19+WSC construction) or custom-made end connections.

> Request product

Ropes in the 6x19S+FC construction impress with their special flexibility and smooth surface, making them ideal for use in manure removal systems. We offer this special rope made of high-quality stainless steel in the standard diameters of 8 mm and 10 mm. It is extremely resistant to corrosion and mechanical stress, making it ideal for intensive, continuous use in agriculture.

For ropes in the 6x19S+FC design, we offer custom-fit end fittings such as shackles, thimbles, eyelets and other connecting elements on request. Especially in industrial applications or in agriculture, a secure and resilient connection is crucial for the reliable functioning of the entire system. Our individually configurable end pieces ensure that the rope can be optimally integrated and fastened.

We have a wide selection of wire ropes by the meter and in stock for you – including the tried-and-tested 6x19S+FC construction as well as many other variants for a wide range of applications. Thanks to our extensive stock of different diameters, materials and designs, you can react flexibly and quickly to your needs without long delivery times.

Warrington-Seale, lay direction, fiber core – technical terms are often used for wire ropes that are not immediately familiar to everyone. On our overview page, we explain the most important terms and show you what is important when choosing the right wire rope construction. At the same time, you will receive a comprehensive overview of the constructions, materials and designs available from us.

If you have any further questions or require an individual solution, we will be happy to assist you personally – together we will find the right wire rope for your application.
